S1934
19" Color LCD Monitor
19" Square Monitor with IPS Panel for Offices and Control Rooms
EIZO’s five-year warranty is two years or 67% longer than the standard three-year warranty of most brands. Even if the initial purchase price of the FlexScan S1934 is higher than another 19-inch monitor, the TCO (total cost of ownership) will likely be lower due to the significantly longer buying cycle and less need for repair.
Our Contribution to SDGs
| As part of its sustainability initiatives, EIZO is contributing towards the United Nations' Sustainable Development Goals (SDGs). | |
 |
| Environmentally Conscious FlexScan are sustainable monitors made using recycled plastics and without using any paints. They are designed to promote energy efficiency for reduced power consumption and greenhouse gas emissions, and are supported by a responsible after-service recycling system. |
|
   |
| |
|
|
| Higher Work Efficiency FlexScan monitors implement numerous innovative technologies and software that aim to improve work efficiency and contribute to the reduction of eye fatigue. |
|
 |
| Model Variations | S1934-HBK: with Height Adjustable Stand, black S1934-HGY: with Height Adjustable Stand, gray S1934-TBK: with Tilt Stand, black S1934-TGY: with Tilt Stand, gray S1934-FBK: without stand, black S1934-FGY: without stand, gray Note: Stand is removable |
|---|---|
| Panel | |
| Type | IPS |
| Backlight | LED |
| Size | 19" (48.0 cm) |
| Native Resolution | 1280 x 1024 (5:4 aspect ratio) |
| Viewable Image Size (H x V) | 374.8 x 299.8 mm |
| Pixel Pitch (H x V) | 0.293 x 0.293 mm |
| Pixel Density | 87 ppi |
| Display Colors | 16.77 million |
| Viewing Angles (H / V, typical) | 178° / 178° |
| Brightness (typical) | 250 cd/m2 |
| Contrast Ratio (typical) | 1000:1 |
| Response Time (typical) | 14 ms (gray-to-gray) |
| Color Gamut (typical) | sRGB |
| Video Signals | |
| Input Terminals | DisplayPort (HDCP 1.3), DVI-D (HDCP 1.4), D-Sub mini 15 pin |
| Digital Scanning Frequency (H / V) | 31 - 64 kHz / 59 - 61 Hz |
| Analog Scanning Frequency (H / V) | 31 - 64 kHz / 55 - 61 Hz |
| Sync Formats | Separate |
| Audio | |
| Speakers | 0.5 W + 0.5 W |
| Input Terminals | Stereo mini jack, DisplayPort |
| Output Terminals | Headphones (Stereo mini jack) |
| Power | |
| Power Input | AC 100 - 240 V, 50 / 60 Hz |
| Typical Power Consumption | 9 W |
| Maximum Power Consumption | 21 W |
| Power Save Mode | 0.5 W or less |
| Features & Functions | |
| Preset Modes | User1, User2, sRGB, Paper, DICOM |
| Automatic Brightness Control | Auto EcoView |
| OSD Languages | English, German, French, Italian, Japanese, Simplified Chinese, Spanish, Swedish, Traditional Chinese |
| Physical Specifications | |
| Dimensions (Landscape, W x H x D) | S1934-H: 405 x 406.5 - 506.5 x 205 mm S1934-T: 405 x 414 x 205 mm |
| Dimensions (Without Stand, W x H x D) | 405 x 334 x 61.5 mm |
| Net Weight | S1934-H: 5.6 kg S1934-T: 4.6 kg |
| Net Weight (Without Stand) | 3.8 kg |
| Height Adjustment Range | S1934-H: 100 mm S1934-T: - |
| Tilt | S1934-H: 30° Up, 0° Down S1934-T: 30° Up, 5° Down |
| Swivel | S1934-H: 35° Right / 35° Left S1934-T: - |
| Pivot | S1934-H: 90° (clockwise) S1934-T: - |
| Hole Spacing (VESA Standard) | 100 x 100 mm |
| Environmental Requirements | |
| Operating Temperature | 5 - 35°C |
| Operating Humidity (R.H., non condensing) | 20 - 80% |
| Certifications & Standards (Please contact EIZO for the latest information.) | TUV/Ergonomics, TUV/GS, RCM, CE, UKCA, CB, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC, EAC |
| Supplied Accessories (May vary by country. Please contact EIZO for details.) | |
| Signal Cables | DVI-D (2 m) , D-Sub mini 15 pin (1.8 m) |
| Others | AC power cord (2 m), audio cable (2.1 m), setup guide |
| Warranty | 5 Years |
| Dimension Drawing |
