EV2430
24.1" Color LCD Monitor
The Perfect Office All-Rounder
The EV2430 is perfect for any office; providing energy savings, reducing eye fatigue, and offering a unique ergonomic design, this is the helpful all-rounder that every office can use.
Effortless Eye-Care
To prevent eye fatigue, a brightness sensor called Auto EcoView detects the changes in the ambient brightness that occur throughout the day and automatically adjusts the screen to the ideal brightness level. Auto EcoView cuts power by almost 40% compared to operating the monitor at maximum brightness.
The FlexScan EV2430 has 178° horizontal and vertical viewing angles which makes it suitable for most business use.
Due to the way brightness is controlled on LED backlights, a small number of people perceive flicker on their screen which causes eye fatigue. The FlexScan EV2430 utilizes a hybrid solution to regulate brightness and make flicker unperceivable without any drawbacks like compromising color stability.Simple, Minimalist Design
Slim bezels
A thin bezel design saves space on the desktop and minimizes eye movement between screens in a multi-monitor environment.
Ergonomic Stand
|
Adjust the screen to your ideal viewing position with EIZO’s versatile FlexStand.
|
 |
Helping the Environment
Compliance with International Labels
Meets the most stringent international labels for ergonomics and energy savings.
Our Contribution to SDGs
| As part of its sustainability initiatives, EIZO is contributing towards the United Nations' Sustainable Development Goals (SDGs). | |
 |
| Environmentally Conscious FlexScan are sustainable monitors made using recycled plastics and without using any paints. They are designed to promote energy efficiency for reduced power consumption and greenhouse gas emissions, and are supported by a responsible after-service recycling system. |
|
   |
| |
|
|
| Higher Work Efficiency FlexScan monitors implement numerous innovative technologies and software that aim to improve work efficiency and contribute to the reduction of eye fatigue. |
|
 |
Equipped for a Long Life
Getting Connected
Three input terminals are included for connecting to PCs. In addition, a USB hub and headphone/ audio jacks are conveniently located on the side of the monitor.
A manufacturer’s 5-year warranty covers all components including the LCD panel to ensure a long service life. This warranty is 2-years or 67% longer than the standard 3-year warranty of most monitor brands for significantly lower running costs.
EIZO guarantees this product will be free from bright sub-pixels for six months from purchase date.
| Model Variations | EV2430-GY: with FlexStand, gray EV2430-BK: with FlexStand, black EV2430-FGY: without stand, gray EV2430-FBK: without stand, black Note: FlexStand is removable |
|---|---|
| Panel | |
| Type | IPS |
| Backlight | LED |
| Size | 24.1" (61.1 cm) |
| Native Resolution | 1920 x 1200 (16:10 aspect ratio) |
| Viewable Image Size (H x V) | 518.4 x 324 mm |
| Pixel Pitch (H x V) | 0.270 x 0.270 mm |
| Pixel Density | 94 ppi |
| Display Colors | 16.77 million |
| Viewing Angles (H / V, typical) | 178° / 178° |
| Brightness (typical) | 300 cd/m2 |
| Contrast Ratio (typical) | 1000:1 |
| Response Time (typical) | 14 ms (gray-to-gray) |
| Color Gamut (typical) | sRGB |
| Video Signals | |
| Input Terminals | DisplayPort (HDCP 1.3), DVI-D (HDCP 1.4), D-Sub mini 15 pin |
| Digital Scanning Frequency (H / V) | 31 - 76 kHz / 59 - 61 Hz |
| Analog Scanning Frequency (H / V) | 31 - 76 kHz / 55 - 61 Hz |
| Sync Formats | Separate |
| USB | |
| Upstream | USB 2.0: Type-B |
| Downstream | USB 2.0: Type-A x 2 |
| Audio | |
| Speakers | 1.0 W + 1.0 W |
| Input Terminals | Stereo mini jack, DisplayPort |
| Output Terminals | Headphones (Stereo mini jack) |
| Power | |
| Power Input | AC 100 - 240 V, 50 / 60 Hz |
| Typical Power Consumption | 12 W |
| Maximum Power Consumption | 36 W |
| Power Save Mode | 0.3 W or less |
| Features & Functions | |
| Preset Modes | User1, User2, sRGB, Paper, Movie |
| Automatic Brightness Control | Auto EcoView |
| OSD Languages | English, German, French, Italian, Japanese, Simplified Chinese, Spanish, Swedish, Traditional Chinese |
| Others | Screen Adjustment (Clock, Phase, Position, Range (Auto), Screen Size (full screen, enlarge), Smoothing (5 stages), Border Intensity, Color Adjustment (Brightness, Contrast, Gamma, Temperature, Saturation, Hue, Gain, Reset), Signal Switching, Product Information (name, serial number, resolution, operating time, etc.), OSD Menu Settings, Adjustment Lock, DDC/CI Lock, Power Indicator, Reset |
| Physical Specifications | |
| Dimensions (Landscape, W x H x D) | 552.5 x 368 - 499 x 233 mm |
| Dimensions (Without Stand, W x H x D) | 552.5 x 358 x 56.9 mm |
| Net Weight | 6.7 kg |
| Net Weight (Without Stand) | 4.3 kg |
| Height Adjustment Range | 131 mm |
| Tilt | 35° Up, 5° Down |
| Swivel | 344° |
| Pivot | 90° (clockwise) |
| Hole Spacing (VESA Standard) | 100 x 100 mm |
| Environmental Requirements | |
| Operating Temperature | 5 - 35°C |
| Operating Humidity (R.H., non condensing) | 20 - 80% |
| Certifications & Standards (Please contact EIZO for the latest information.) | EPEAT Bronze, TUV/Ergonomics, TUV/Low blue light content, TUV/Flicker Free, TUV/GS, RCM, CE, UKCA, CB, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC, EAC |
| Supplied Accessories (May vary by country. Please contact EIZO for details.) | |
| Signal Cables | DisplayPort (2 m), DVI-D (2 m) |
| Others | AC power cord (2 m), VESA mounting screw x 4 (EV2430-F), setup guide |
| Warranty | 5 Years Zero bright sub-pixels for six months from date of purchase. |
| Dimension Drawing |
- 2 With current LCD / OLED technology, a panel may contain a limited number of missing or flickering pixels.
- 5 If the monitor is left on continuously over a long period of time, dark smudges or burn-in may appear. To maximize the life of the monitor, we recommend the monitor be turned off periodically.
- 16 EPEAT registration varies by country. Please check https://www.epeat.net for registration status.
